An image that ripples like liquid wherever the pointer moves: refraction, colour splitting and a glint on every crest.

Move across it. Click to drop a stone.
npx @agents-npm-packages/vibeui add ripple-image --dir ./src/components/uiImport
import { RippleImage } from "@/components/ui/ripple-image"Generated from the component's TypeScript types, so it always matches the source. * marks a required prop.
also accepts every HTMLAttributes<HTMLDivElement> attribute
| Prop | Type | Default | Description |
|---|---|---|---|
| src* | string | — | Image URL. |
| alt* | string | — | Describes the image. Required, because this is content, not decoration. |
| strength | number | 1 | How hard the ripples bend the image. 0 turns them off. |
"use client";
import * as React from "react";
import { cn } from "@/lib/utils";
const QUERY = "(prefers-reduced-motion: reduce)";
function useReducedMotion() {
return React.useSyncExternalStore(
(notify) => {
const mq = window.matchMedia(QUERY);
mq.addEventListener("change", notify);
return () => mq.removeEventListener("change", notify);
},
() => window.matchMedia(QUERY).matches,
() => false,
);
}
const VERT = `attribute vec2 p; void main(){ gl_Position = vec4(p, 0.0, 1.0); }`;
const FRAG = `
#ifdef GL_FRAGMENT_PRECISION_HIGH
precision highp float;
#else
precision mediump float;
#endif
uniform sampler2D uTex;
uniform vec2 uRes;
uniform vec2 uImg;
uniform float uTime;
uniform float uStrength;
uniform vec4 uR[8];
vec2 cover(vec2 uv){
float rs = uRes.x / uRes.y;
float is = uImg.x / uImg.y;
vec2 s = rs > is ? vec2(1.0, is / rs) : vec2(rs / is, 1.0);
return (uv - 0.5) * s + 0.5;
}
void main(){
vec2 uv = gl_FragCoord.xy / uRes;
float aspect = uRes.x / uRes.y;
vec2 off = vec2(0.0);
float shine = 0.0;
for (int i = 0; i < 8; i++){
vec4 r = uR[i];
float age = uTime - r.z;
if (age < 0.0 || age > 3.0) continue;
vec2 d = uv - r.xy;
d.x *= aspect;
float dist = length(d);
float w = dist - age * 0.5;
float env = exp(-w * w * 190.0) * exp(-age * 1.5) * r.w;
float wave = sin(w * 52.0);
off += (d / (dist + 0.0001)) * wave * env * 0.024;
shine += wave * env;
}
off *= uStrength;
off.x /= aspect;
vec2 t = clamp(cover(uv + off), 0.0, 1.0);
float cr = texture2D(uTex, clamp(cover(uv + off * 1.35), 0.0, 1.0)).r;
float cg = texture2D(uTex, t).g;
float cb = texture2D(uTex, clamp(cover(uv + off * 0.65), 0.0, 1.0)).b;
vec3 col = vec3(cr, cg, cb) + shine * 0.11 * uStrength;
gl_FragColor = vec4(col, 1.0);
}`;
/**
* An image that ripples like liquid wherever the pointer moves: refraction, colour splitting and a glint on every crest.
*
* It is a real `<img>` underneath, so it works without WebGL, without JavaScript and with reduced motion.
*/
export function RippleImage({
src,
alt,
strength = 1,
className,
...props
}: Omit<React.HTMLAttributes<HTMLDivElement>, "children"> & {
src: string;
/** Describes the image. Required, because this is content, not decoration. */
alt: string;
/** How hard the ripples bend the image. 0 turns them off. */
strength?: number;
}) {
const wrap = React.useRef<HTMLDivElement>(null);
const canvas = React.useRef<HTMLCanvasElement>(null);
const reduce = useReducedMotion();
const live = React.useRef({ strength });
React.useEffect(() => {
live.current = { strength };
}, [strength]);
React.useEffect(() => {
const host = wrap.current;
const cv = canvas.current;
if (!host || !cv || reduce) return;
const gl = cv.getContext("webgl", {
antialias: false,
alpha: false,
powerPreference: "low-power",
});
if (!gl) return;
const compile = (type: number, source: string) => {
const sh = gl.createShader(type)!;
gl.shaderSource(sh, source);
gl.compileShader(sh);
return sh;
};
const prog = gl.createProgram()!;
gl.attachShader(prog, compile(gl.VERTEX_SHADER, VERT));
gl.attachShader(prog, compile(gl.FRAGMENT_SHADER, FRAG));
gl.linkProgram(prog);
if (!gl.getProgramParameter(prog, gl.LINK_STATUS)) return;
gl.useProgram(prog);
const buf = gl.createBuffer();
gl.bindBuffer(gl.ARRAY_BUFFER, buf);
gl.bufferData(gl.ARRAY_BUFFER, new Float32Array([-1, -1, 1, -1, -1, 1, 1, 1]), gl.STATIC_DRAW);
const loc = gl.getAttribLocation(prog, "p");
gl.enableVertexAttribArray(loc);
gl.vertexAttribPointer(loc, 2, gl.FLOAT, false, 0, 0);
const uRes = gl.getUniformLocation(prog, "uRes");
const uImg = gl.getUniformLocation(prog, "uImg");
const uTime = gl.getUniformLocation(prog, "uTime");
const uStrength = gl.getUniformLocation(prog, "uStrength");
const uR = gl.getUniformLocation(prog, "uR");
// A ring buffer of ripples: x, y (0 to 1), start time (s), amplitude.
const ripples = new Float32Array(32).fill(0);
for (let i = 0; i < 8; i++) ripples[i * 4 + 2] = -100;
let head = 0;
const t0 = performance.now();
const now = () => (performance.now() - t0) / 1000;
const spawn = (x: number, y: number, amp: number) => {
ripples.set([x, y, now(), amp], head * 4);
head = (head + 1) % 8;
kick();
};
let ready = false;
let imgW = 1;
let imgH = 1;
let w = 1;
let h = 1;
const resize = () => {
const r = host.getBoundingClientRect();
const dpr = Math.min(window.devicePixelRatio || 1, 1.5);
w = Math.max(Math.round(r.width * dpr), 2);
h = Math.max(Math.round(r.height * dpr), 2);
cv.width = w;
cv.height = h;
gl.viewport(0, 0, w, h);
};
const draw = () => {
gl.uniform2f(uRes, w, h);
gl.uniform2f(uImg, imgW, imgH);
gl.uniform1f(uTime, now());
gl.uniform1f(uStrength, live.current.strength);
gl.uniform4fv(uR, ripples);
gl.drawArrays(gl.TRIANGLE_STRIP, 0, 4);
};
// Render only while a ripple is alive, so an idle image costs nothing.
let raf = 0;
const frame = () => {
draw();
const t = now();
let alive = false;
for (let i = 0; i < 8; i++) if (t - ripples[i * 4 + 2] < 3) alive = true;
raf = alive ? requestAnimationFrame(frame) : 0;
};
function kick() {
if (ready && !raf) raf = requestAnimationFrame(frame);
}
const img = new Image();
img.crossOrigin = "anonymous";
img.onload = () => {
const tex = gl.createTexture();
gl.bindTexture(gl.TEXTURE_2D, tex);
gl.pixelStorei(gl.UNPACK_FLIP_Y_WEBGL, true);
gl.texImage2D(gl.TEXTURE_2D, 0, gl.RGBA, gl.RGBA, gl.UNSIGNED_BYTE, img);
gl.texParameteri(gl.TEXTURE_2D, gl.TEXTURE_WRAP_S, gl.CLAMP_TO_EDGE);
gl.texParameteri(gl.TEXTURE_2D, gl.TEXTURE_WRAP_T, gl.CLAMP_TO_EDGE);
gl.texParameteri(gl.TEXTURE_2D, gl.TEXTURE_MIN_FILTER, gl.LINEAR);
gl.texParameteri(gl.TEXTURE_2D, gl.TEXTURE_MAG_FILTER, gl.LINEAR);
imgW = img.naturalWidth || 1;
imgH = img.naturalHeight || 1;
ready = true;
resize();
draw();
cv.style.opacity = "1";
};
img.src = src;
let lx = 0;
let ly = 0;
let lt = 0;
const onMove = (e: PointerEvent) => {
if (!ready) return;
const r = host.getBoundingClientRect();
const x = e.clientX - r.left;
const y = e.clientY - r.top;
const moved = Math.hypot(x - lx, y - ly);
const t = performance.now();
if (moved > 38 && t - lt > 55) {
const speed = Math.min(moved / Math.max(t - lt, 1), 3);
spawn(x / r.width, 1 - y / r.height, 0.55 + Math.min(speed, 1.6) * 0.45);
lx = x;
ly = y;
lt = t;
}
};
const onDown = (e: PointerEvent) => {
if (!ready) return;
const r = host.getBoundingClientRect();
spawn((e.clientX - r.left) / r.width, 1 - (e.clientY - r.top) / r.height, 1.6);
};
host.addEventListener("pointermove", onMove);
host.addEventListener("pointerdown", onDown);
const ro = new ResizeObserver(() => {
resize();
if (ready) draw();
});
ro.observe(host);
resize();
return () => {
cancelAnimationFrame(raf);
ro.disconnect();
host.removeEventListener("pointermove", onMove);
host.removeEventListener("pointerdown", onDown);
img.onload = null;
gl.getExtension("WEBGL_lose_context")?.loseContext();
};
}, [src, reduce]);
return (
<div
{...props}
ref={wrap}
className={cn("relative aspect-[4/3] w-full overflow-hidden", className)}
>
{/* eslint-disable-next-line @next/next/no-img-element */}
<img src={src} alt={alt} className="absolute inset-0 size-full object-cover" />
<canvas
ref={canvas}
aria-hidden
className="absolute inset-0 size-full opacity-0 transition-opacity duration-500"
/>
</div>
);
}
Exports RippleImage. Peer dependencies: clsx, tailwind-merge.
